Our Ceramic plates are exceptional quality...
Reliable...
Ceramic Rifle
Plates of Alumina Oxide 98%, bonded to Aramid fiber:
- exceed protection
levels as specified by NIJ 01.0105, and
- manufactured
to ISO 9001 quality assurance standards (International Standards
Organization).
Plates you can
stake your life on with confidence:
Armor Piercing
Threats Stopped:
|
Caliber
|
Bullet
|
Typical
Weapon
|
| 7.62
× 51mm |
M-61
AP (Armor Piercing) |
Battle
Rifles and Machine Guns |
| 7.62
× 54mm |
Russian
Light Penetrating Steel (R LPS) |
Dragunov
Sniper Rifle |
| 7.62
× 63mm |
M2
- AP (Armor Piercing) |
|
Not
Just "One-Hit Wonders"
Full-size
plates are tested to be BOTH Level III AND Level IV
When used as
directed, our Ceramic Rifle Plates will defeat MULTIPLE, spaced*
hits of common rifle ammunition threats:
|
Caliber
|
Bullet
|
Typical
Weapon
|
7.62
× 51mm
.308 Winchester |
FMJ
"NATO ball" |
Battle
Rifles and Machine Guns |
| 7.62
× 39mm |
Mild
Steel Core |
AK-47
|
| 5.45
× 39mm |
FMJ
Ball |
Russian
AK-74 |
5.56
x 45mm
.223 |
M855
SS-109 |
M-16 |
5.56
x 45mm
.223 |
FMJ
M193 |
M-16
and AR-15 |
| 7.62
× 54mm |
FMJ |
Dragunov
Sniper Rifle |
| 12
Gauge |
Lead
Slug |
Shotgun |
* yes, if
2 rounds hit in almost exactly the same spot you are probably
out of luck! The NIJ test standard is a minimum 2" (5 cm.)
spacing between rounds, and 3" (8 cm.) from the edge of plate.
Our Ceramic
Rifle Plates are the full thickness out to the edge of the plate
(as far as practical). We DON'T cut corners lightening up a plate
by "cheating the test" and thinning the outer edge of
the plate.
Lighter...
Designing
the plate to work in conjunction with a vest, as an integrated
system, gives you Level III and IV protection and saves ~4 pounds
of weight (1.8 kg.) over a pair of plates!
Ergonomic...
Many Rifle
Plates are only curved in one dimension, but all our full-size
Ceramic plates are curved in THREE dimensions to more closely
conform to your body contours – like a moulded breast-plate
or back-plate. This means a snugger fit and less bouncing when
you move, not to mention better protection, and less bulk
to hinder your movement.
Rifle Plates
For Use with a Level III-A Vest Supporting\
Most sizes in stock for
immediate shipment
|
Ballistic
Protection Level
|
Size
|
Weight
|
Price
|
|
10"
by 12"
|
|
|
Level
III AND Level
IV
WITH A LEVEL III-A VEST SUPPORTING
***
Triple Curved
to hug your body.
|
~0.6"
thick
~
15 mm.
|
|
|
FRONT
"Shooters
Cut" clipped top corners for best buttstock placement
and ergonomics
|
~9.5"
Wide by 11.5" Tall
~24 by 29 cm.
|
Front
~6 lbs.
~2.7 kg.
|
$
220 each
(Pair Price)
$ 230 each
|
|
BACK
Rectangular
with rounded corners.
Check to ensure
your Rifle Plate Pockets will take the full value rectangular plate. |
Back
~6.5 lbs.
~2.95 kg.
|
$
220 each
(Pair Price)
$ 230 each
|
Please
know that many Eagle, BlackHawk and other plate carriers are NOT
designed for the more rectangular Back plates (only clipped corner
plates even on the back). You may need to order two Front plates
to fit your carrier.
It
is your responsibility to verify compatibility with your equipment.
Special
on Older Production
(Customer
Returns that have sat in our warehouse waiting for an X-Ray)
|
Freshly
X-rayed to Validate Safety.
|
|
Level
III AND Level
IV
WITH A LEVEL III-A VEST SUPPORTING
***
Triple Curved
to hug your body.
|
~0.6"
thick
~
15 mm.
|
|
|
FRONT
"Shooters
Cut" clipped top corners for best buttstock placement
and ergonomics
|
~9.5"
Wide by 11.5" Tall
~24 by 29 cm.
|
Front
~6 lbs.
~2.7 kg.
|
$
140 each
(Pair Price)
$ 150 each
|
|
BACK
Rectangular
with rounded corners.
Check to ensure
your Rifle Plate Pockets will take the full value rectangular plate. |
Back
~6.5 lbs.
~2.95 kg.
|
$
140 each
(Pair Price)
$ 150 each
|
Oversize coverage
in an Alumina Oxide / aramid plate. Fits Large and bigger Interceptor
OTV (Outer Tactical Vest) - or other vests with OVERSIZE Rifle Plate
Pockets.
-
Oversized
and double-curved.
-
~20%
more coverage than a regular 10" by 12"
plate in a body-hugging design.
-
Tapered
at the top for more freedom of movement and precise weapon shouldering
directly to your shoulder (instead of over armor).
|
Ballistic
Protection Level
|
Size
|
Weight
|
Price
|
|
10"
by 13"
|
For
size Large and up Interceptor OTV / IBAS
|
|
|
Level
III AND Level
IV
WITH A LEVEL III-A VEST SUPPORTING
***
|
~0.6"
thick
~
15 mm.
|
|
|
Triple
Curved SAPI shape
Both Front
& Back top corners tapered for comfort and ergonomics.
|
~10"
Wide by 13" Tall
~25 by
33 cm.
|
~7.5
lbs.
3.4 kg.
|
$
250 each
(Pair Price)
$ 260 each
|
| |
|
11"
by 14"
|
For
size XL and up Interceptor OTV / IBAS
|
|
Level
III AND Level
IV
WITH A LEVEL III-A VEST SUPPORTING
*** |
~0.6"
thick
~
15 mm.
|
|
|
Triple
Curved SAPI shape
Both Front
& Back top corners tapered for comfort and ergonomics.
|
~11"
by 14"
~28 by
35 cm.
|
~8.5
lbs.
3.9 kg.
|
$
280 each
(Pair Price)
$ 290 each
|
|
8"
by 10"
|
Size
|
|
|
Level
IV
WITH A LEVEL III-A VEST SUPPORTING
***
Double Curved
(too small to be triple curved)
|
|
|
|
FRONT
"Shooters
Cut" clipped top corners for best buttstock placement
and ergonomics
BACK
Rectangle
with Rounded Corners.
|
|
~4.4
lbs.
~2.0 kg.
|
$
195 each
|
***
These Ceramic Plates are Level III or IV ONLY WHEN COMBINED WITH
THE APPROPRIATE LEVEL VEST, i.e., plate is NOT stand-alone III or
IV.
MUST be combined
with the appropriate, QUALITY vest to get the full ballistic protection.
|
WARNING:
U.S. EXPORT CONTROL LAWS
Level III and IV
armor (Rifle Plates) fall under the jurisdiction of the International
Traffic in Arms Regulations (ITAR), and is subject to the export control
laws of the U.S. Government. Export
or retransfer of Rifle Plates by any means to any foreign end user,
or for any other end use, whether in the U.S. or abroad, without the
written approval of the U.S.
Department of State, is prohibited.
There is often an
exemption for a U.S. person taking their personal protection with them
in their luggage, and returning the armor to the US. For the requirements,
click here.
One of the forms required may be found here.
|
Ceramic
Rifle Plates are NOT RETURNABLE
(except for warranty). Ceramic Rifle
Plates can be damaged if abused, or improperly shipped, and we
cannot accept that legal liability. Carefully
measure your Rifle Plate Pockets for inside dimensions
to see what plate size - and shape - you need. Please
know that many Eagle, BlackHawk and other plate carriers are not
designed for the more rectangular Back plates (only clipped corner
plates even on the back). You may need to order two Front plates
to fit your carrier. It
is your responsibility to verify compatibility with your equipment.
|
